22
IGNITION
SYSTEM
EZ
Stator winding - check lor a short circuit
bJ
ground (terminal 31)
Measure the resistance between the specified points.
Stator, connector
EZ
pin 1 - Measuring point
Ground
(-)
I Resistance
•
If
the value displayed does not meet specifications:
- Change the stator.
22A
Ramovillllha
stator
Condition
The alternator cover has
been
removed.
-
Remove
screw and take off the cable holder.
-
Remove
cable support sleeve from the alternator
case.
-
Remove
screws
- Take the stator out
of
the alternator cover.
- Position the stator in the alternator cover.
- Mount and tighten screws
Guideline
Screw,
stator
M5 6
Nm
(4.4
Ibf
It)
- Position cable support sleeve in the alternator case.
- Position the cable holder. Mount and tighten screw
Guideline
Screw, cable holder in
alternator cover
M4
4Nm
(3
Ibf ft)
210
Loctite-
243'"
Loctit"
243'"
