ELECTRICAL SYSTEM 143
B00644-10
– Remove screws .
– Remove the rear top part.
B00646-10
– Pull bulb sockets carefully out of the bracket.
– Remove the bulb.
– Position a new light bulb in the socket.
Tail light (W5W/socket W2.1x9.5d) ( p. 196)
– Carefully position the sockets with the bulbs into the bracket in the tail light.
– Check that the tail light bulbs are functioning properly.
B00644-10
– Position the rear top part.
– Mount and tighten screws .
Guideline
Remaining chassis screws M5 5 Nm (3.7 lbf ft)
Remaining frame bolts EJOT PT K50x18
T20
2 Nm (1.5 lbf ft)
