SERVICE WORK ON THE CHASSIS 95
700572-01
– Shift the transmission to neutral.
– Pull the lower chain section with specified weight .
Guideline
Weight, chain wear measurement 15 kg (33 lb.)
– Measure the distance of 18 chain links in the lower chain section.
Info
Chain wear is not always even, so you should repeat this measurement at differ-
ent chain positions.
Maximum distance at the longest
chain section
272 mm (10.71 in)
» If distance is greater than the specified measurement:
–
Replace the chain. x
Info
When the chain is replaced, the rear sprocket and engine sprocket
should also be changed.
New chains wear out faster on old, worn sprockets.
For safety reasons, the chain has no chain joint.
