Kubler Sendix 58 Series - Product Description; Technical Data Sendix 58 xx

Kübler Group 3 Product Description
HB Profibus Interface - R67068.0002 - 01 EN - 7
3 Product Description
3.1 Technical Data Sendix 58xx
Mechanical characteristics for the Sendix 58xx encoders
Maximum rotational speed
IP65 up to 70°C
IP65 up to Tmax
IP67 up to 70°C
IP67 up to Tmax
9000 min-1,
7000 min-1 (continuous operation)
7000 min-1,
4000 min-1 (continuous operation)
8000 min-1,
6000 min-1 (continuous operation)
6000 min-1,
3000 min-1 (continuous operation)
Starting torque (at 20°C)
IP65
IP67
<0.01 Nm
<0.05 Nm
Mass moment of inertia
Shaft version
Hollow shaft version
3.0 x 10
-6
kgm
2
7.5 x 10
-6
kgm
2
(MT)
6 x 10
-6
kgm
2
(ST)
Permissible shaft load
radial
axial
80 N
40 N
Protection level acc. to EN60529
Housing side
Shaft side
IP67
IP65, opt. IP67
Working temperature range -40°C ... +80°C
Materials
Shaft/hollow shaft
Flange
Housing
Stainless steel
Aluminum
Die-cast zinc
Shock resistance according to EN60068-2-27 2.500 m/s
2
, 6 ms
Vibration resistance according to EN60068-2-6 100 m/s
2
, 55 ... 2000 Hz
Electrical data for the Sendix 58xx encoders
Supply voltage 10 … 30 V DC
Current consumption (no load)
10…30VDC max. 110 mA
Supply voltage reverse polarity protection Yes
