Kübler Group 5 Commissioning and Operation
HB Profibus Interface - R67068.0002 - 01 EN - 29
Input word Input word Format Max.
Byte 0 Byte 1 Byte 2 Byte 3 - -
0 0 RPM 0
17 70 RPM 6000
E8 90 RPM -6000
00 63 FF 9C Unit/s 6553500
FF 9C 00 64 Unit/s -6553500
Rotational speed limitations
NOTICE
Calculation basis for the speed (steps/s).
The physical singleturn is always assumed as the calculation basis
(65536 steps/revolution) when setting the speed (steps/s).
Singleturn encoders: 600 rpm higher rotational speeds produce value ffffh
Multiturn encoders: 12,000 rpm higher rotational speeds produce value ffffh
5.4.3 Station Address
The station address is set by means of the two address rotary switches. Default address at de-
livery is 0x3F (63 dec.)
NOTICE
Setting the station address (software or
hardware side)
These settings have higher priority than the software setting of the
master. With devices without removable bus cover, the default setting
is 0xFFh for the software.
