Kubler Sendix 58 Series - Technical Data Sendix 70 xx

3 Product Description Kübler Group
8 - EN HB Profibus Interface - R67068.0002 - 01
Interface PROFIBUS PROFIBUS DP V0
Encoder profile Class 2
Encoder profile 3062 V1.1
Resolution
Singleturn (MUR)
Multiturn (NDR)
Total resolution (TMR)
Max. 28 bits (default 25 bits)
Max. 12 bits
Max. 28 bits (default 25 bits)
Type of connection 3 x M12 connector
3.2 Technical Data Sendix 70xx
Mechanical data for Sendix 70xx
Maximum rotational speed 6000min
-1
Maximum angular acceleration 5x10
5
rad/s²
Operating/storage and
transport temperature range
-40°C...+60°C [-40°F…140°F]
Protection level according to EN 60529 IP67
Protection level according to NEMA 250 Type6
Installation height <2000m [6562ft]
Shock resistance according to EN/IEC60068-2-27 500m/s
2
, 11ms
Vibration resistance according to EN/IEC60068-2-6 5...2000Hz, 200m/s
2
Electrical data for the Sendix 70xx encoders
Supply voltage
(depending on the variant)
5 V DC
5 … 30 V DC
10 … 30 V DC
Current consumption (no load)
5 V DC
5 … 30 V DC
10 … 30 V DC
max. 90 mA
max. 100 mA
max. 100 mA
Protection class according to EN61140 III (PELV)
EMC - Electromagnetic Compatibility
Relevant Standards EN55011 classB:2009/A1:2010
EN61326-1:2013
Interface PROFIBUS PROFIBUS DP V0
Encoder profile Class 2
Encoder profile 3062 V1.1
Resolution
Singleturn (MUR)
Multiturn (NDR)
Total resolution (TMR)
Max. 16 bits (default 13 bits)
Max. 12 bits
Max. 28 bits (default 25 bits)
Type of connection 3 x M12 connector
