Kübler Group 5 Commissioning and Operation
HB Profibus Interface - R67068.0002 - 01 EN - 19
NOTICE
Reset via the SET key
Note that, for devices with external SET key, all programmed para-
meters are lost (except the station address, which has been assigned
by SSA). See Set Slave Address (SSA) [}31].
A reset with the SET key is only possible for devices with external
SET key.
Performing an external position reset:
a) Switch the encoder off.
b) When switching it back on, hold the SET key pressed for about 3 seconds, until the DIAG
LED flashes.
c) Switch the device off again.
ð When switching it on again, all values will be reset to the default settings.
If errors occurred during the programming of the objects, and if these parameters are saved in
the EPROM, addressing the encoder will not be possible when switching it on the next time.
This error can only be corrected by a general Reset of the encoder.
Also refer to
2 Extended Diagnostic [}36]
5.2.2 Configuring the Modules
To be able to perform a general parameterizing of the device, the corresponding GSD file must
be selected and implemented first (e.g. KUEB7068.GSD). It can be found on the Kübler web
page of the concerned product.
The respective software allows including the GSD files.
