Kübler Group 4 Installation
HB Profibus Interface - R67068.0002 - 01 EN - 11
4 Installation
4.1 Electrical Installation
4.1.1 General Information for the Connection
ATTENTION
Destruction of the device
Before connecting or disconnecting the signal cable, always discon-
nect the power supply and secure it against switching on again.
NOTICE
Current limitation
Use a suitable external fuse for encoder protection, for a maximum
current of 500 mA.
NOTICE
General safety instructions
Make sure that the whole plant remains switched off during the elec-
trical installation.
• Make sure that the operating voltage is switched on or off simultan-
eously for the device and the downstream device.
• Use a PELV supply voltage source according to EN60204-1 with
the proper operating voltage and the maximum permissible output
current.
4.1.2 Terminal Assignment 58xx
PROFIBUS connection M12 connector
