Kubota DF972-E2 - Check Points of Initial 50 Hours

G-8
WG972-E2, DF972-E2, WSM
G GENERAL
Checking Air Cleaner Element (If necessary)
1. To clean the element, use clean dry compressed air on the inside
of the element.
Air pressure at the nozzle must be under 205 kPa (2.1 kgf/cm
2
,
30 psi).
2. If the element is stained with carbon or oil, replace the element.
IMPORTANT
■
•Make sure the wing bolt for the element is tight enough. If it
is loose, dust and dirt may be sucked, wearing down the
cylinder liner and piston ring earlier and thereby resulting in
poor power output.
•Do not overservice the air cleaner element.
NOTE
■
•Replace the element once a year or every 6th cleaning.
W1030585
Checking the Setting of LPG Fuel Tank (If necessary) (DF972-
E2)
Check the setting of LPG fuel tank.
W1031085
Checking the Connector (DF972-E2)
Check the connector in LPG line (hoses and clamps).
W1031214
[2] CHECK POINTS OF INITIAL 50 HOURS
Changing Engine Oil
CAUTION
•Be sure to stop engine before changing engine oil.
1. Start and warm up the engine for approx. 5 minutes.
2. Place an oil pan underneath the engine.
3. To drain the used oil, remove the drain plug (1) at the bottom of
the engine and drain the oil completely.
4. Screw the drain plug (1).
5. Fill new oil up to upper line on the dipstick (2).
IMPORTANT■
•When using an oil of different maker or viscosity from the
previous one, remove all of the old oil.
•Never mix two different types of oil.
•Engine oil should have properties of API classification SH.
•Use the proper SAE Engine Oil according to ambient
temperature.
W1016604
Above 25 °C (77 °F) SAE30 or SAE10W-30
0 °C to 25 °C (32 °F to 77 °F) SAE20 or SAE10W-30
Below 0 °C (32 °F) SAE10W or SAE10W-30
Engine oil capacity
3.4 L
3.59 U.S.qts
Tightening torque Drain plug
32.4 to 37.3 N·m
3.3 to 3.8 kgf·m
23.9 to 27.5 ft-lbs
(1) Drain Plug (2) Dipstick
KiSC issued 01, 2006 A
