G-21
WG972-E2, DF972-E2, WSM
G GENERAL
Replacing Radiator Hoses and Clamp Bands
CAUTION
•Do not remove the radiator cap when the engine is hot. Then
loosen cap slightly to the stop to relieve any excess
pressure before removing cap completely.
1. Drain the coolant.
2. Loosen the clamp bands.
3. Remove the upper hose (1) and lower hose (2).
4. Replace new upper / lower hose (1), (2) and clamp bands.
5. Tighten the clamp bands.
6. Fill with clean water and anti-freeze until the coolant level is just
below the port. Install the radiator cap securely.
W1024178
(1) Upper Hose (2) Lower Hose
