Kubota M7040 - INSTRUMENT PANEL AND CONTROLS; Instrument Panel, Switches and Hand Controls

4 INSTRUMENT PANEL AND CONTROLS
INSTRUMENT PANEL AND CONTROLS
B Instrument Panel, Switches and Hand Controls
ILLUSTRATED CONTENTS
(1) Hydraulic-shuttle shift lever
[Hydraulic shuttle model] ............................
D
(1) Synchro-shuttle shift lever
[Synchro shuttle model] ..............................
D
(2) Clutch pedal ...............................................
D
(3) Tilt pedal ....................................................
D
(4) Turn signal / Head light switch .................... 11, 11
(5) Hazard light switch ..................................... 11
(6) Horn button ................................................
D
(7) Key switch .................................................
D
(8) Foot throttle ...............................................
D
(9) Brake pedal ...............................................
D
D See operator's manual issued separately for the sister model. [M6040, M7040, M8540, M9540]
