OPERATING THE TRACTOR14
OPERATING TECHNIQUES
BTrailer Electrical Outlet
A trailer electrical outlet is supplied for use with trailer or
implement.
C Function of each terminals in trailer electrical
outlet
(1) Trailer electrical outlet
Terminal Function
(1) Turn signal light (LH)
(2) ---
(3) Ground
(4) Turn signal light (RH)
(5)
Tail light
Sidemarker light
Parking light
(6) Brake stop light
(7) Registration plate light
