Kubota V3300-E2B - Page 71

S-8
V3300-E2B, V3300-T-E2B, WSM
DIESEL ENGINE
ENGINE BODY (Continued)
W1013874
Item Factory Specification Allowable Limit
Timing Gear
Idle Gear 1 to Crank Gear
Idle Gear 1 to Cam Gear
Idle Gear 1 to Idle Gear 2
Idle Gear 2 to Injection Pump Gear
Cam Gear to Balancer Gear 1
(Balancer Model Only)
Idle Gear 1 to Balancer Gear 2
(Balancer Model Only)
Backlash
Backlash
Backlash
Backlash
Backlash
Backlash
0.049 to 0.193 mm
0.0019 to 0.0076 in.
0.049 to 0.189 mm
0.0019 to 0.0074 in.
0.044 to 0.185 mm
0.0017 to 0.0073 in.
0.044 to 0.177 mm
0.0017 to 0.0070 in.
0.047 to 0.182 mm
0.0018 to 0.0072 in.
0.044 to 0.183 mm
0.0017 to 0.0072 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
Idle Gear Shaft 1, 2 to Idle Gear 1, 2
Bushing
Idle Gear 1, 2 Bushing
Idle Gear 1, 2 Shaft
Oil Clearance
I.D.
O.D.
0.050 to 0.091 mm
0.0020 to 0.0036 in.
45.025 to 45.050 mm
1.7726 to 1.7736 in.
44.959 to 44.975 mm
1.7700 to 1.7707 in.
0.10 mm
0.0039 in.
–
–
Idle Gear Side Clearance 0.15 to 0.30 mm
0.0059 to 0.0118 in.
0.9 mm
0.0354 in.
Balancer Shaft (Balancer Model Only) Side Clearance 0.070 to 0.22 mm
0.0028 to 0.0087 in.
0.3 mm
0.0118 in.
Balancer Shaft (Balancer Model Only) Alignment – 0.02 mm
0.0008 in.
Balancer Shaft (Balancer Model Only)
Balancer Shaft Journal
Balancer Bearing
Oil Clearance
O.D.
I.D.
0.070 to 0.159 mm
0.0028 to 0.0063 in.
50.92 to 50.94 mm
2.0047 to 2.0055 in.
51.01 to 51.08 mm
2.0083 to 2.0110 in.
0.2 mm
0.0079 in.
–
–
Piston Pin Bore I.D. 30.000 to 30.013 mm
1.1811 to 1.1816 in.
30.05 mm
1.1831 in.
Second Ring to Ring Groove Clearance 0.093 to 0.120 mm
0.0037 to 0.0047 in.
0.20 mm
0.0079 in.
Oil Ring to Ring Groove Clearance 0.020 to 0.060 mm
0.0008 to 0.0023 in.
0.15 mm
0.0059 in.
KiSC issued 06, 2006 A
