S-13
V3300-E2B, V3300-T-E2B, WSM
DIESEL ENGINE
[2] TIGHTENING TORQUES FOR SPECIAL USE SCREWS, BOLTS AND
NUTS
NOTE
• For “*” marked screws, bolts and nuts on the table, apply engine oil to their threads and seats before
tightening.
• The letter “M” in Size x Pitch means that the screw, bolt or nut dimension stands for metric. The size is
the nominal outside diameter in mm of the threads. The pitch is the nominal distance in mm between two
threads.
W1013236
Item Size x Pitch N·m kgf·m ft-lbs
Cylinder head cover screw – 6.9 to 11.3 0.7 to 1.15 5.1 to 8.32
*Cylinder head screw M12 x 1.25 98.1 to 107.9 10.0 to 11.0 72.3 to 79.6
*Connecting rod screw M10 x 1.25 78.5 to 83.4 8.0 to 8.5 57.9 to 61.5
*Flywheel screw M12 x 1.25 98.1 to 107.9 10.0 to 11.0 72.3 to 79.6
*Crankshaft screw M16 x 1.5 255.0 to 274.6 26.0 to 28.0 188.1 to 202.5
*Main bearing case screw M14 x 1.5 137.3 to 147.1 14.0 to 15.0 101.3 to 108.5
Rocker arm bracket screw M10 x 1.25 49.0 to 55.9 5.0 to 5.7 36.2 to 41.2
Nozzle holder assembly M20 x 1.5 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Nozzle holder – 34.3 to 39.2 3.5 to 4.0 25.3 to 28.9
Injection pipe retaining nut M12 x 1.5 22.6 to 36.3 2.3 to 3.7 16.6 to 26.8
Overflow pipe assembly retaining nut M12 x 1.5 19.6 to 24.5 2.0 to 2.5 14.5 to 18.1
Oil switch taper screw R 1/8 14.7 to 19.6 1.5 to 2.0 10.8 to 14.5
Oil cooler joint screw – 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
Oil pump cover screw – 7.9 to 9.3 0.80 to 0.95 5.8 to 6.9
Glow plugs M10 x 1.25 19.6 to 24.5 2.0 to 2.5 14.5 to 18.1
Starter’s terminal B mounting nut M8 x 1.25 9.8 to 11.8 1.0 to 1.2 7.2 to 8.7
Injection pump gear mounting nut M14 x 1.5 73.6 to 83.4 7.5 to 8.5 54.2 to 61.5
Injection pump unit mounting nut M8 x 1.25 17.7 to 20.6 1.8 to 2.1 13.0 to 15.2
Gear case cover M8 x 1.25 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Relief valve retaining screw – 68.6 to 78.4 7.0 to 8.0 50.6 to 57.9
Idle gear mounting screw M8 x 1.25 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Plate mounting screw M8 x 1.25 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Camshaft set screw M8 x 1.25 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Flywheel housing mounting screw M12 x 1.25 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Crankcase 2 mounting screw M10 x 1.25 49.0 to 55.9 5.0 to 5.7 36.2 to 41.2
Injection pump mounting screw M8 x 1.25 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Injection pump mounting nut M8 x 1.25 17.7 to 20.6 1.8 to 2.1 13.0 to 15.2
Boost actuator
(Boost compensator model only)
– 39.2 to 45.1 4.0 to 4.6 28.9 to 33.3
Governor weight mounting nut M12 x 1.25 62.8 to 72.6 6.4 to 7.4 46.3 to 53.5
Fuel camshaft stopper mounting screw – 7.9 to 9.3 0.80 to 0.95 5.8 to 6.9
To Next Page
