S-14
V3300-E2B, V3300-T-E2B, WSM
DIESEL ENGINE
W1013236
Item Size x Pitch N·m kgf·m ft-lbs
Governor housing mounting screw M6 x 1.0 9.8 to 11.3 1.00 to 1.15 7.23 to 8.32
Anti-rotation nut M5 x 0.8 2.8 to 4.0 0.29 to 0.41 2.1 to 3.0
Balancer shaft set screw
(Balancer model only)
M8 x 1.25 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Bearing case cover mounting screw M8 x 1.25 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Alternator pulley nut – 58.3 to 78.9 5.95 to 8.05 43.0 to 58.2
