S-5
05-E3B, 05-E3BG, WSM
DIESEL ENGINE
2. SERVICING SPECIFICATIONS
ENGINE BODY
W11299120
Item Factory Specification Allowable Limit
Valve Clearance (Cold) 0.145 to 0.185 mm
0.00571 to 0.00728 in.
–
Compression Pressure
Difference among Cylinders
D1005-E3B / E3BG
D1105-E3B / E3BG
D1305-E3B / E3BG
V1505-E3B / E3BG
D1105-T-E3B
V1505-T-E3B
3.73 to 4.11 MPa
38.0 to 42.0 kgf/cm
2
541 to 597 psi
3.14 to 3.53 MPa
32.0 to 36.0 kgf/cm
2
456 to 512 psi
–
2.26 MPa
23.0 kgf/cm
2
327 psi
2.26 MPa
23.0 kgf/cm
2
327 psi
10 % or less
Top Clearance D1005-E3B / E3BG
D1105-E3B / E3BG
D1105-T-E3B
V1505-E3B / E3BG
V1505-T-E3B
D1305-E3B / E3BG
0.55 to 0.75 mm
0.022 to 0.029 in.
0.80 to 1.0 mm
0.032 to 0.039 in.
–
–
Cylinder Head Surface Flatness – 0.05 mm
0.002 in.
Valve Recessing Intake and Exhaust −0.050 to 0.25 mm
−0.0020 to 0.0098 in.
0.40 mm
0.016 in.
Valve Stem to Valve Guide
Valve Stem
Valve Guide
Clearance
O.D.
I.D.
0.035 to 0.065 mm
0.0014 to 0.0025 in.
6.960 to 6.975 mm
0.2741 to 0.2746 in.
7.010 to 7.025 mm
0.2760 to 0.2765 in.
0.10 mm
0.0039 in.
–
–
Valve Face Angle (Intake)
Angle (Exhaust)
1.0 rad
60 °
0.79 rad
45 °
–
–
Valve Seat Angle (Intake)
Angle (Exhaust)
Width
1.0 rad
60 °
0.79 rad
45 °
2.12 mm
0.0835 in.
–
–
–
