S-6
05-E3B, 05-E3BG, WSM
DIESEL ENGINE
ENGINE BODY (Continued)
W1131278
Item Factory Specification Allowable Limit
Valve Spring Free Length
Tilt
Setting Load
37.0 to 37.5 mm
1.46 to 1.47 in.
–
117.4 N / 31.0 mm
11.97 kgf / 31.0 mm
26.39 lbf / 1.22 in.
36.5 mm
1.44 in.
1.0 mm
0.039 in.
100.0 N / 31.0 mm
10.20 kgf / 31.0 mm
22.48 lbf / 1.22 in.
Rocker Arm Shaft to Rocker Arm
Rocker Arm Shaft
Rocker Arm
Clearance
O.D.
I.D.
0.016 to 0.045 mm
0.00063 to 0.0017 in.
11.973 to 11.984 mm
0.47138 to 0.47181 in.
12.000 to 12.018 mm
0.47244 to 0.47314 in.
0.10 mm
0.0039 in.
–
–
Push Rod Alignment – 0.25 mm
0.0098 in.
Tappet to Tappet Guide
Tappet
Tappet Guide
Clearance
O.D.
I.D.
0.020 to 0.062 mm
0.00079 to 0.0024 in.
19.959 to 19.980 mm
0.78579 to 0.78661 in.
20.000 to 20.021 mm
0.78740 to 0.78822 in.
0.07 mm
0.003 in.
–
–
Timing Gear
Crank Gear to Idle Gear 1
Idle Gear 1 to Cam Gear
Idle Gear 1 to Injection Pump Gear
Idle Gear 1 to Idle Gear 2
Idle Gear 2 to Governor Gear
Backlash
Backlash
Backlash
Backlash
Backlash
0.0320 to 0.115 mm
0.00126 to 0.00452 in.
0.0360 to 0.114 mm
0.00142 to 0.00448 in.
0.0340 to 0.116 mm
0.00134 to 0.00456 in.
0.0330 to 0.117 mm
0.00130 to 0.00460 in.
0.0300 to 0.117 mm
0.00119 to 0.00460 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
Governor Gear
Governor Gear to Injection Pump
Gear
Backlash 0.0300 to 0.117 mm
0.00119 to 0.00460 in.
0.15 mm
0.0059 in.
