[2] TIGHTENING TORQUES FOR SPECIAL USE SCREWS, BOLTS AND
NUTS
NOTE
• For “ * ” marked screws, bolts and nuts on the table, apply engine oil to their threads and seats before
tightening.
• The letter “M” in Size x Pitch means that the screw, bolt or nut dimension stands for metric. The size is
the nominal outside diameter in mm of the threads. The pitch is the nominal distance in mm between two
threads.
W1013236
Item Size x Pitch N·m kgf·m lbf·ft
Cylinder head cover screw
[D1005-E3B / E3BG, D1105-E3B / E3BG,
D1105-T-E3B, V1505-E3B / E3BG,
V1505-T-E3B]
M7 x 1.0 7 to 8 0.7 to 0.9 5 to 6
Cylinder head cover screw
[D1305-E3B / E3BG]
M6 x 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
Cylinder head screw M10 x 1.25 64 to 68 6.5 to 7.0 47 to 50
*Main bearing case screw 1 M8 x 1.25 30 to 34 3.0 to 3.5 22 to 25
*Main bearing case screw 2 M9 x 1.25 49 to 53 5.0 to 5.5 37 to 39
*Flywheel screw M10 x 1.25 54 to 58 5.5 to 6.0 40 to 43
*Connecting rod screw M8 x 1.0 42 to 46 4.2 to 4.7 31 to 33
*Rocker arm bracket nut
[D1005-E3B / E3BG, D1105-E3B / E3BG,
D1105-T-E3B, V1505-E3B / E3BG,
V1505-T-E3B]
M7 x 1.0 22 to 26 2.2 to 2.7 16 to 19
*Rocker arm bracket screw
[D1305-E3B / E3BG]
M7 x 1.0 22 to 26 2.2 to 2.7 16 to 19
*Idle gear shaft screw M6 x 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
*Fan drive pulley screw M14 x 1.5 236 to 245 24.0 to 25.0 174 to 180
Bearing case cover mounting screw M6 x 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
Glow plug M8 x 1.0 7.9 to 14 0.80 to 1.5 5.8 to 10
Nozzle holder assembly M20 x 1.5 49 to 68 5.0 to 7.0 37 to 50
Nozzle holder – 35 to 39 3.5 to 4.0 26 to 28
Oil pressure switch PT 1/8 15 to 19 1.5 to 2.0 11 to 14
Injection pipe retaining nut M12 x 1.5 25 to 34 2.5 to 3.5 18 to 25
Overflow pipe retaining nut M12 x 1.5 20 to 24 2.0 to 2.5 15 to 18
Starter’s B terminal nut M8 5.88 to 11.8 0.600 to 1.20 4.34 to 8.70
Alternator’s pulley nut – 58.4 to 78.9 5.95 to 8.05 43.1 to 58.2
Drain plug with copper gasket M12 x 1.25 33 to 37 3.3 to 3.8 24 to 27
Drain plug with rubber coated gasket M22 x 1.5 45 to 53 4.5 to 5.5 33 to 39
