S-7
05-E3B, 05-E3BG, WSM
DIESEL ENGINE
ENGINE BODY (Continued)
W11326040
Item Factory Specification Allowable Limit
Idle Gear Shaft to Gear Bushing
Idle Gear 1
Idle Gear Bushing
Idle Gear Shaft 1
Idle Gear 2
Idle Gear Bushing
Idle Gear Shaft 2
Clearance
I.D.
O.D.
Clearance
I.D.
O.D.
0.020 to 0.054 mm
0.00079 to 0.0021 in.
26.000 to 26.021 mm
1.0237 to 1.0244 in.
25.967 to 25.980 mm
1.0224 to 1.0228 in.
0.020 to 0.054 mm
0.00079 to 0.0021 in.
26.000 to 26.021 mm
1.0237 to 1.0244 in.
25.967 to 25.980 mm
1.0223 to 1.0228 in.
0.10 mm
0.0039 in.
–
–
0.10 mm
0.0039 in.
–
–
Idle Gear
Idle Gear 1
Idle Gear 2
Side Clearance
Side Clearance
0.20 to 0.51 mm
0.0079 to 0.020 in.
0.20 to 0.51 mm
0.0079 to 0.020 in.
0.80 mm
0.031 in.
0.80 mm
0.031 in.
Camshaft Side Clearance
Alignment
0.070 to 0.22 mm
0.0028 to 0.0086 in.
–
0.30 mm
0.012 in.
0.01 mm
0.0004 in.
Cam Height Intake
Exhaust
28.80 mm
1.134 in.
29.00 mm
1.142 in.
28.75 mm
1.132 in.
28.95 mm
1.140 in.
Camshaft Journal to Cylinder Block Bore
Camshaft Journal
Cylinder Block Bore
Oil Clearance
O.D.
I.D.
0.050 to 0.091 mm
0.0020 to 0.0035 in.
35.934 to 35.950 mm
1.4148 to 1.4153 in.
36.000 to 36.025 mm
1.4174 to 1.4183 in.
0.15 mm
0.0059 in.
–
–
Piston Pin Bore I.D. 22.000 to 22.013 mm
0.86615 to 0.86665 in.
22.03 mm
0.8673 in.
Piston Pin to Small End Bushing
Piston Pin
Small End Bushing
Clearance
O.D.
I.D.
0.014 to 0.038 mm
0.00056 to 0.0014 in.
22.002 to 22.011 mm
0.86622 to 0.86657 in.
22.025 to 22.040 mm
0.86713 to 0.86771 in.
0.15 mm
0.0059 in.
–
–
KiSC issued 12, 2007 A
