S-8
05-E3B, 05-E3BG, WSM
DIESEL ENGINE
ENGINE BODY (Continued)
Item Factory Specification Allowable Limit
Piston Ring Gap
[D1005-E3B / E3BG]
Top Ring 0.30 to 0.45 mm
0.012 to 0.017 in.
1.25 mm
0.0492 in.
Second Ring 0.30 to 0.45 mm
0.012 to 0.017 in.
1.25 mm
0.0492 in.
Oil Ring 0.25 to 0.40 mm
0.0098 to 0.015 in.
1.25 mm
0.0492 in.
Piston Ring Gap
[D1105-E3B / E3BG]
[D1105-T-E3B]
[V1505-E3B / E3BG]
[V1505-T-E3B]
Top Ring 0.20 to 0.35 mm
0.0079 to 0.013 in.
1.20 mm
0.0472 in.
Second Ring 0.40 to 0.55 mm
0.016 to 0.021 in.
1.20 mm
0.0472 in.
Oil Ring 0.30 to 0.55 mm
0.012 to 0.021 in.
1.25 mm
0.0492 in.
Piston Ring Gap
[D1305-E3B / E3BG]
Top Ring 0.20 to 0.35 mm
0.0079 to 0.013 in.
1.20 mm
0.0472 in.
Second Ring 0.30 to 0.45 mm
0.012 to 0.017 in.
1.25 mm
0.0492 in.
Oil Ring 0.30 to 0.55 mm
0.012 to 0.021 in.
1.25 mm
0.0492 in.
Piston Ring to Piston Ring Groove
[D1005-E3B / E3BG]
Second Ring
Oil Ring
Clearance
Clearance
0.0850 to 0.112 mm
0.00335 to 0.00440 in.
0.020 to 0.055 mm
0.00079 to 0.0021 in.
0.2 mm
0.008 in.
0.15 mm
0.0059 in.
Piston Ring to Piston Ring Groove,
[D1105-E3B / E3BG], [D1105-T-E3B],
[V1505-E3B / E3BG], [V1505-T-E3B]
Second Ring
Oil Ring
Clearance
Clearance
0.0950 to 0.122 mm
0.00374 to 0.00480 in.
0.020 to 0.060 mm
0.00079 to 0.0023 in.
0.2 mm
0.008 in.
0.15 mm
0.0059 in.
Piston Ring to Piston Ring Groove
[D1305-E3B / E3BG]
Second Ring
Oil Ring
Clearance
Clearance
0.0850 to 0.112 mm
0.00335 to 0.00440 in.
0.020 to 0.060 mm
0.00079 to 0.0023 in.
0.2 mm
0.008 in.
0.15 mm
0.0059 in.
Connecting Rod Alignment – 0.05 mm
0.002 in.
Crankshaft Alignment – 0.02 mm
0.0008 in.
KiSC issued 12, 2007 A
