Mower conditioner
40
FC243
Instructions for work
Finger conditioning rotor speed
The machine is equipped with a finger conditioning rotor.
The rotor speed can be set at 888 min
-1
or 615 min
-1
.
The machine is factory set at a rotor speed of 888 min
-1
.
Rotor speed adjustment:
With the machine in transport position.
Remove self-locking nut of pivoting guardrail using the
box spanner supplied with the machine (1).
Pivot guardrail tube (2).
Remove the 3 self-locking nuts using box spanner.
Remove belt guard.
Always place the machine in transport
position before making rotor speed
(rotational frequency) adjustments.
Turn off the engine, remove ignition key and
wait until all moving parts have come to a
complete stop.
