Mower conditioner
40
FC302RG - FC352RG
Instructions for transport
KN271BGB C
- Release and lift side guard using 18mm box spanner
supplied with the machine:
• (a): Position wrench.
• (b): Unlock and raise side guards.
- Lock guard in raised position using spring (1).
- Proceed the same way on the other side.
The machine is in transport position.
Opened position (1).
Closed position (2).
Never engage the tractor PTO drive when the
machine is in transport position.
