Maintenance and storage
Mower conditioner
FC302RG - FC352RG
77
KN271BGB C
Disc replacement
- Place a wooden wedge (2) between two discs to stop
them from moving.
- Remove 4 bolts (1) and their spring washers using the
box spanner supplied with the machine.
- Remove the disc.
When remounting:
- Position their largest diameters at right angles to each
other.
- Position conical centre of spring washer at the top.
- Torque bolts to (12 daN m / 89 lbf ft).
