KUHN GMD44 - Page 30

Remove the mounting bolts (1).
Separate the half gearcases.
Recover spacers (1).
Remove lower gearcase o - ring (2).
To prevent damaging the threads and jamming
the nylon bush on the bolt:
Loosen mounting bolts (1) of a few turns, going
from the cutter bar oustide towards the center.
Step 6.
