From 786384 to .......
Reinstall ball bearing (3).
Reinstall snap rings (1) and (2).
See sheet.
Position intermediate gearwheel flat part towards the half
casing.
Insert intermediate gearwheel using a hollow tube of
diameter smaller than the inner bearing cage. The blue
retaining ring must be able to nest itself into the hollow part of the punch used.
Before reinstalling the intermediate pinions,
position helical pinions making sure to respect the
disk synchronization.
See sheet.
