Kuschall Compact Series User Manual

ProductOverview
InstallingtheArmrest
1.InstallthearmrestcoverHtothearmrestassembly
ifnotyetattached.
2.InsertjointpinGofthearmrestassemblyintothejoint
Funtilitengageswithanaudible“click”.
3.Swivelthearmrestassemblydownwardsintothe
armrestholderEuntilthereleaseleverhookD
engageswithanaudible“click”.
4.PulloutthespringboltlockBandinsertthebarof
theT-armrestpadAintotheholderCtotherequired
height.
TheT-armrestpadcanoptionallybeinserted180°
turned.
5.Releasethespringboltlockandallowthebarofthe
T-armrestpadtoengagewithanaudible“click”inthe
nearesthole.
AdjustingtheHeight
1.PulloutthespringboltlockBandmovethearmrest
padAtotherequiredheight.
2.Releasethespringboltlockandallowittoengagewith
anaudible“click”inthenearesthole.
WARNING!
RiskofInjury
Evenifthearmrestsarelocking,theyarenot
designedtocarrytheweightoftheoccupied
wheelchair.
–Neverusethearmreststoliftthewheelchair.
–Donotusethearmrestsfortransportation
whencarryingthewheelchairup-ordownstairs.
3.8.4Mudguard
Inordertopreventdirtfromthewheelssprayingupwards,
aremovablemudguardcanbetted.Thepositionofthe
mudguardcanbeadjusted.Theadjustmentmustbecarried
outbyaqualiedtechnician.
1659285-A19

Kuschall Compact Series Specifications

General

Foldable	Yes
Frame Material	Aluminum
Max User Weight	130 kg
Wheel Size	24 inches
Total Weight	From 9.3 kg (depending on configuration)
