Kuschall Compact Series User Manual

Küschall®Compact
11TechnicalData
11.1DimensionsandWeight
A
Seatdepth
320–500mm,inincrements
of20mm
B
Backrestangle
82°/86°/90°/94°/98°/102°
C
Lowerleglength
200–510mm,inincrements
of10mm
D
Frontseat-to-oor
height
370–530mm,inincrements
of10mm
E
Rearseat-to-oor
height
360–500mm,inincrements
of10mm
F
Backrestheight
300–510mm,inincrements
of15mm
G
Overalllengthwith
legrest
70°frameangle:
approx.870–1220mm
80°frameangle:
approx.850–1200mm
H
Seatwidth
280–500mm,inincrements
of20mm
I
Overallwidth
Overallwidth,folded
Seatwidth+180mm
approx.290mm
Foldedlength70°frameangle:
approx.870–1220mm
80°frameangle:
approx.850–1200mm
J
Overallheight
approx.660–1060mm
Foldedheight
approx.660–1060mm
561659285-A

Kuschall Compact Series Specifications

General

Foldable	Yes
Frame Material	Aluminum
Max User Weight	130 kg
Wheel Size	24 inches
Total Weight	From 9.3 kg (depending on configuration)
