Küschall®Compact
WARNING!
Riskofinjury
Themudguardsarenotlockedandcanbeeasily
pulledoutupwards.
–Donotliftortransferthewheelchairusingthe
mudguards.
–Donotusethemudguardsfortransportation
whencarryingthewheelchairup-ordownstairs.
Removing
1.Pullthemudguardupwardsoutoftheholder.
2.Toadjusthoweasyordifcultitistopullthemudguard
outoftheholder,changethedegreetowhichthe
screwsDaretightened.
Installing
1.Pushthemudguardintotheholder.
Adjustingtheheight
1.SlightlyloosenthegrubscrewAontheclampingpart
B.
2.Movetheclampingpartupwardsordownwardsonthe
proleCtothedesiredheight.
3.Re-tightenthegrubscrew.
4.Performthesettingonbothsides.
3.8.5Clothes-guard
Aclothes-guardcanbeinstalledtoprotectyourclothes.
3.9Legrests
WARNING!
Riskofinjury
–Neverusethelegrestsorfootplatestoliftthe
wheelchair.
Swivelling
1.ActivatethereleaseleverAandswivelthelegrestB
totheoutside.
Swivellingforwards
1.Swivelthelegrestforwardsuntilitengages.
201659285-A

Kuschall Compact Series Specifications

General

Foldable	Yes
Frame Material	Aluminum
Max User Weight	130 kg
Wheel Size	24 inches
Total Weight	From 9.3 kg (depending on configuration)
