76
RADIATOR
Periodically check the radiator area for cleanliness.
Inspect radiating fins. They must be clean, free of mud, dirt,
leaves and any other deposit that would prevent the radiator to
cool properly. Remove as much as you can with your hands. If
water is available in proximity, try rinsing the radiating fins.
If available, use a garden hose to rinse the radiating fins.
Never clean radiator with your hands when it is hot. Let the
radiator cool down before cleaning.
SHOCK ABSORBERS
Each shock absorber on your ATV should be visibly checked
weekly for excessive fluid leakage (some seal leakage is normal),
cracks or breaks in the shock body, or a bent shock rod. If any
one of the conditions is detected, replacement is necessary.
NOTE: If you ride your ATV in extremely cold weather
(-10°F/ -23°C or colder), a small amount of fluid leakage
may occur on the shock rod. Unless the leakage is
excessive, replacement of the shock absorber is not
necessary.
The shock absorbers have spring force adjustment sleeves with
five positions to allow the spring rate to be adjusted for
different riding and loading conditions. If the spring rate is too
soft or too stiff, adjust the sleeve according to the chart below.
NOTE: Use a spanner wrench to adjust the spring force
adjustment sleeve to the desired position.
