2 Installation and commissioning
2.1 Hardware installation
The software is supplied on a Compact Flash card (‘CF card’). To use this card, it has
to be kept permanently in the printer. All you have to do to install the card is to insert
it into the slot in the printer.
Note that, for technical reasons, starting with Version 3.00 the Barcode Flash solution
is available as Type A and Type B. The following multifunctional printers (MFP)
require Type B:
KM-3050, KM-4050, KM-5050, KM-3040, KM-3060
All other printers and MFP require Type A.
Where differences exist between the installation of Type A and Type B, these are
described below. Please ensure that the proper installation is available on the
compact flash card. You can use the directory to determine whether this is the case
and reprogram the card if necessary. You can do so by copying the right file to the
printer. Please observe the instructions in this regard at the beginning of the update
file.
Please nothe that only the PCL Barcode Flash cards can be re-programmed by the
end user. The KYOmulticode card (PCL Barcode Flash with Unicode font extension
and additional fonts) has to be re-programmed by Kyocera Mita customer service if a
change between Type A and B or vice versa is necessary.
N
Please note carefully the general tips on working with CF cards in your printer
manual. This manual will also contain a description of where the CF slot is on
your particular device.
ote
Data and programs for Kyocera Mita printers always have to be present in a
particular form on Compact Flash cards. In the case of the barcode solution, these
are a number of what are known as ‘partitions’ in which additional fonts and macros
for the status page and function calls are stored for the user in addition to the
software.
The following partitions are available once the CF card has been inserted:
Type A:
Barcode Status
Barcode Init
Barcode Remove
KM BC 3.00.1
BSTP
STP1
STP2
KM_Logo
17

Kyocera Ecosys FS-1320D Specifications

General

Ethernet LAN	No
Network ready	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Processor model	405F5
Processor family	PowerPC
Maximum internal memory	544 MB
Display	LED
Certification	TÜV/GS, CE, PTS, C-Tick
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.2 W
Power consumption (printing)	544 W
Power consumption (PowerSave)	4.3 W
Media thickness	0.11 mm
Compatible operating systems	Windows OS Linux OS Unix OS Mac OS X 10.2+

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
