Kyocera ECOSYS FS-3920DN Operation Guide

Using the Operation Panel 2-7
Cursor Keys
The four cursor keys are used in the menu system to access an item or
enter numeric values. Use U and V to change menus, and Y and Z to
move to the sub menu.
The cursor key with the question mark ( ) may be pressed when the
paper jam message has appeared on the message display. A help
message will then appear to facilitate jam clearing in the location.
When Use alternative? is shown in the message display, use the U
and V key to select the paper source.
OK Key
This key is used to:
• Finalize settings of numeric values and other selections.
• Set the paper source when Use alternative? is shown in the
message display.

Kyocera ECOSYS FS-3920DN Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm
Memory	128 MB, expandable to 640 MB
Dimensions	390 x 285 mm
Weight	14.1 kg
