A-13
Appendix
Paper Types
â€
Cassette, Optional
Paper Feeder PF-
520
Plain, preprinted, bond, recycled, rough, letterhead, color, prepunched, thick,
high quality, and custom
Optional Paper
Feeder PF-530
Plain, preprinted, labels, bond, recycled, rough, letterhead, color, prepunched,
envelope, cardstock, coated, thick, high quality, and custom
MP Tray Plain, transparency, preprinted, labels, bond, recycled, vellum, rough,
letterhead, color, prepunched, envelope, cardstock, coated, thick, high quality,
and custom
Paper Feed
Source Capacity
Cassette 250 sheets (80 g/m
2
) 500 sheets (80 g/m
2
)
MP Tray 50 sheets (80 g/m
2
) 50 sheets (80 g/m
2
)
Margin 4 mm (left, right, top and bottom)
Output Tray
Capacity
Top Tray 250 sheets (80 g/m
2
)
Operation
Environment
Temperature 10 to 32.5 °C (50 to 90.5 °F)
Relative Humidity 15 to 80 %
Altitude 2,500 m (8,202 feet) maximum
Illumination 1,500 lux maximum
Power Source 120 V, 60 Hz, max. 8.5 A (U.S.A./Canada) 220-240 V, 50 Hz/60 Hz, max. 4.5 A
(European countries) Max. allowable voltage fluctuation: ±10 % Max. allowable
frequency fluctuation: ±2 %
Power
Consumption
Maximum 1,068 W or less (U.S.A./Canada)
1,129 W or less (European countries)
1,111 W or less (U.S.A./Canada)
1,169 W or less (European countries)
Operating Noise
†â€
During Printing LpA = 61.7 dB (A)
During Standby LpA = 43 dB (A)
During Sleep
Mode
immeasurably low
Dimensions (W × D × H) 390 × 523 × 370 mm
15-3/8 × 20-9/16 × 14-9/16"
390 × 523 × 397 mm
15-3/8 × 20-9/16 × 15-5/8"
Weight Approx. 28 kg (61.7 lbs) Approx. 31.5 kg (69.4 lbs)
†. When using CUSTOM 1 (to 8), use the MP tray for paper sizes smaller than 105 × 148 mm (4-1/8 × 5-13/16
inches). The MP tray can be used with paper sizes over 70 × 138 mm (2-3/4 × 5-7/16 inches).
††. Sound pressure level at bystander position [front] in accordance with EN ISO 7779.
Item
Description
FS-C5150DN FS-C5250DN
