3-15
Handling Paper
5 While pressing the release lever, slide the paper stopper to the
desired paper size.
Standard paper sizes are marked on the inside of the paper cassette.
6 Slide the paper into the paper cassette.
7 Insert the paper cassette into the slot in the printer. Push it straight in
as far as it will go.
There is a paper gauge on the right side of the front of the paper
cassette to indicate the remaining paper supply. When paper is
exhausted, the pointer will go down to the level of (empty).
Release
Lever
Paper Stopper
Load Limit
Load Limit
Note Do not load more paper than will fit under the load limits
on the paper guides.
The paper cassette will hold approximately 500 sheets of 80 g/
m² (21 lb.) paper with a thickness of 0.11 mm. (The FS-
C5150DN will hold approximately 250 sheets of paper with a
thickness of 0.11 mm/sheet. )
Paper Gauge
To Next Page
