Kyocera ECOSYS M2040dn User Manual

3-22
Preparation before Use > Registering Destinations in the Address Book
The Folder (FTP) Address
1 [◄] [►] key > [Folder (FTP)] > [Edit]
2 Enter the information for "Host Name (FTP)", "Path", "Login User Name" and "Login
Password" > [OK] key
The table below explains the items to be entered.
3 The connection confirmation screen appears. Select [Yes] to check the connection and
[No] to not check it.
If [SSL] is enabled in [Secure Settings], "Connect with encrypt communication?" will appear after
you select [Yes]. If [Yes] is selected, the FTP encrypted communication connection will be confirmed.
If [No] is selected, you will return to the regular connection confirmation screen.
"Connected." appears when connection to the destination is correctly established. If "Cannot
connect." appears, review the entry.
4
Specify the address number.
1 [◄] [►] key > [Address Number] > [Edit]
2 Enter an address number.
3 Select the [OK] key.
Item Descriptions
Max. No. of
Characters
Host Name (FTP)
*1
*1 If you specify a port number other than the default (21), use the "Host name: port number" (Example:
FTPhostname:140).
To enter the IPv6 address, enclose the address in brackets [ ].
(Example: [3ae3:9a0:cd05:b1d2:28a:1fc0:a1:10ae]:140)
Host name or IP address of FTP server Up to
64 characters
Path
*2
*2 When the FTP server is based on Linux/UNIX, the path including the sub-folder is combined by the
slash "/" not using the back-slash.
Path for the file to be stored
For example: User\ScanData
If no path is entered, the file is stored in the home directory.
Up to
128 characters
Login User Name FTP server login user name Up to
64 characters
Login Password FTP server login password Up to
64 characters
NOTE
Refer to the following for details on entering characters.
Character Entry Method (page 11-8)
NOTE
You can set any value between 1 and 120.
Use the numeric keys or select the [▲] or [▼] key to enter a number.
Address Number is an ID for a destination. You can select any available number.
If you specify an address number that is already in use, an error message appears when
you select the [OK] key and the number cannot be registered.

Kyocera ECOSYS M2040dn Specifications

General

Paper input type	Cassette, Paper tray
Multi-Purpose tray	Yes
Total input capacity	250 sheets
Total output capacity	- sheets
Maximum input capacity	850 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Scan media weight	50 - 160 g/m²
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Paper tray media types	-
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Scan speed (black)	23 ppm
Image formats supported	JPG, MMR, TIF
Duplex scan speed (black)	32 ppm
Duplex scan speed (color)	16 ppm
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Internal memory	512 MB
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound pressure level (copying)	52 dB
Sound pressure level (quiet mode)	48 dB
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	21 W
Power consumption (sleep)	1 W
Power consumption (printing)	661 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	ENERGY STAR
Certification	GS, TÜV, CE, ISO 9001, ISO 14001
Cartridge type	TK-1170

Weight and Dimensions

Depth	412 mm
Width	417 mm
Height	437 mm
Weight	19000 g
