Kyocera ECOSYS M2040dn

To Next Page

To Previous Page

2-4

Installing and Setting up the Machine > Part Names (Connectors/Interior)

Part Names (Connectors/Interior)

1 TEL Connector

2 LINE Connector

3 USB Interface Connector

4 Network Interface Connector

5 Feed Cover

6 Paper Length Guide

7 Paper Width Guides

8 USB Memory Slot

9 Multipurpose Tray

10 Tray Extension

11 Paper Width Guides

12 Fuser Cover

1 2

9 10
