Installing and Setting up the Machine > Part Names
Model with the finisher
1 Document Processor
2 Original Width Guides
3 Original Table
4 Original Eject Table
5 Inner Finisher
6 Tray Extension
7 Inner Tray
8 Paper Stopper
9 Front Cover
10 Cassette 1
11 Power Switch
12 Original Stopper
13 USB Memory Slot
14 Front Cover Open Button
15 Slit Glass
16 Original Size Indicator Plates
17 Platen
18 Operation Panel
19 Staple Cover
20 Handles
1 2 3 4
12
13
15 16
17
18
9
14
7
11
10
20
8
5
19
6
