2T6/2T7/2T8/2T9
2-3-12
YC20 51 C2P_SDAT I DC0V/3.3V Panel transmitted data signal
Connected to
the main
PWB
52 GND - - Ground
53 SDIF_SDCD O DC0V/3.3V Card detect signal
54 SDIF_INTA O DC0V/3.3V Interrupt signal
55 SDIF_CMD I/O DC0V/3.3V Command signal
56 BDN_D O DC0V/3.3V BD signal
57 SH2D I DC0V/3.3V Sample hold signal
58 GND - - Ground
59 LDOUT_2_DN I LVDS
60 LDOUT_2_DP I LVDS
YC21 1 TH3 I Analog FUTH2 output signal
Connected to
the fuser
thermistor
connect
PWB
2 TH1 I Analog FUTH1output signal
3 GND - - Ground
4 REARFANN O 24 V DC REFM: On/Off
5 +24V_F3 O 24 V DC 24 V DC power output to FTHPWB
YC22 1 +24V_F2 O 24 V DC 24 V DC power output to PF
Connected to
the paper
feeder
2 OPSDO O 0/3.3 V DC (pulse) PF communication serial data signal
3 OPSDI I 0/3.3 V DC (pulse) PF communication serial data signal
4 OPCLK O 0/3.3 V DC (pulse) PF communication serial clock signal
5 OPRDYN I 0/3.3 V DC Option communication ready signal
6 +3.3V3_F1 O 3.3 V DC 3.3 V DC power output to PF
7 GND - - Ground
8 OPSEL2 O 0/3.3 V DC PF select signal
9 OPSEL1 O 0/3.3 V DC PF select signal
10 OPSEL0 O 0/3.3 V DC PF select signal
11 OPPAUSEN O 0/3.3 V DC Paper stop signal
12 GND - - Ground
YC23 1 VBUS O 5 V DC 5 V DC power output to USB host
Connected to
the USB host
2 UDATAN I/O LVDS USB data signal (-)
3 UDATAP I/O LVDS USB data signal (+)
4 GND - - Ground
5 GND - - Ground
YC26 1 +3.3V_F2 O 3.3 V DC 3.3 V DC power output to ES
Connected to
the eject sen-
sor
2 GND - - Ground
3 EXITSENSN I 0/3.3 V DC ES: On/Off
Connector Pin Signal I/O Voltage Description
