Kyocera ECOSYS P3050dn

2T6/2T7/2T8/2T9
2-3-13
YC30 1 +3.3V1_F1 O 3.3 V DC 3.3 V DC power output to OPPWB
Connected to
the opera-
tion PWB
2 FUPRSTN O 0/3.3 V DC OPPWB reset signal
3 P2C_OK_KEY I 0/3.3 V DC OK KEY:On/Off
4 C2P_BUZCO
N
O 0/3.3 V DC Buzzer control signal
5 AIRTEMP I Analog Temperature sensor input signal
6 C2P_LCDCO
N
O 0/5 V DC LCD: On/Off
7 +5V5 O 5 V DC 5 V DC power output to LCD
8 P2C_SDAT I 0/3.3 V DC Data signal
9 AIRWET I Analog Humid sensor input signal
10 C2P_SDAT O 0/3.3 V DC The data signal between panel main
11 WETCLK O 0/3.3 V DC (pulse) Humid sensor clock signal
12 LED O 0/3.3 V DC READY LED control signal
13 FG - - Ground
14 GND - - Ground
YC31 1 1WIRE - - -
Connected to
the relay-L
PWB
2 +24V3_IL_F5 O 24 V DC 24 V DC power output
3 GND - - Ground
4 GND - - Ground
5 +24V0_F3 O 24 V DC 24 V DC power output
Connector Pin Signal I/O Voltage Description
