Kyocera ECOSYS P5026cdw User Manual

4-11
Printing from PC > Printing Data Saved in the Printer
Printing Data Saved in the Printer
You can save the print job into the Job Box of this device and print it as necessary. To use the Stored Job Box and the
Quick Copy Box, an SD/SDHC memory card must be installed in the device.
If you configure settings in the [Job] tab of the printer driver and then print, the print job will be saved in the Job Box
(memory) and printing can be executed at the machine.
Follow the work flow below when using Job Box.
Specifying the Job Box from a computer and sending the print job. (page 4-11
)
Using the operation panel to specify a file within a Box and printing it.
You can print the documents from the following boxes.
Printing Document from Quick Copy Box (page 4-12)
Printing Document from Proof and Hold Box (page 4-13)
Printing Documents from Private Print Box (page 4-14)
Printing Document from Stored Job Box (page 4-15)
Specifying the Job Box from a Computer and Storing
the Job
1
Click [File] and select [Print] in the application.
The Print dialog box displays.
2
Select the machine from the "Name" menu.
3
Click the [Properties] button.
The Properties dialog box displays.
4
Click the [Job] tab and select the [Job storage (e-MPS)] check
box to set the function.
IMPORTANT
Unencrypted data is saved on the SD/SDHC memory card.
Exercise caution when saving sensitive documents.
NOTE
If you are using an SD/SDHC memory card to use a job box, set [RAM Disk Mode] to [Off].
NOTE
For information on how to use the printer driver software, refer to the following:
Printer Driver User Guide

Kyocera ECOSYS P5026cdw Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9.5 s
Time to first page (color, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Number of print cartridges	2
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	- sheets
Maximum input capacity	550 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Network ready	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Mobile printing technologies	Google Cloud Print, Mopria Print Service
Standard interfaces	RJ-45, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	A9
Processor family	ARM Cortex
Sound pressure level (printing)	47.4 dB
Sound pressure level (quiet mode)	43.4 dB
Certification	GS, TÜV, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	33 W
Power consumption (printing)	375 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Width	410 mm
Height	329 mm
