Troubleshooting > Clearing Paper Jams

Remove any jammed paper in Rear Cover 1

Open Rear Cover 1.

Remove any jammed paper.

Open the cover (A).

CAUTION

The fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting

burned.
