Kyocera ECOSYS P7035cdn - Page 111

2PR
1-5-25
1-5-8 PWBs
(1) Detaching and refitting the power source PWB
Procedure
1. Remove the right rear cover (See page 1-5-
6).
2. Remove three screws and then remove the
power source shield.
Figure 1-5-33
3. Remove two screws.
Figure 1-5-34
Power source shield
Screw
Screws
Screw
Screw
