2PR
1-5-31
8. Remove five connectors and one FFC from
the engine PWB.
9. Remove three screws.
Figure 1-5-40
YC619
YC614
YC11
YC28
YC33
YC34
FFC
Connector
Connector
Connectors
Engine PWB assembly
Screw
Screw
Screw
Engine PWB
Engine PWB
Engine PWB
assembly
