Kyocera ECOSYS P7035cdn - Page 119

2PR
1-5-33
13. Remove two screws and then remove the
engine PWB.
14. Check or replace the engine PWB and refit
all the removed parts.
To replace the engine PWB, remove the
EEPROM (U4) from the old engine PWB
and mount it to the new engine PWB.
Figure 1-5-43
Engine PWB
EEPROM
U4
Screw
Screw
