Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-4
(2) Self diagnostic codes
Code Contents
Remarks
Causes Check procedures/corrective measures
0100 Backup memory read/write error Defective main
PWB.
Replace the main PWB (See page 1-5-27).
0110 Backup memory data error Defective main
PWB.
Replace the main PWB (See page 1-5-27).
0120 MAC address data error
For data in which the MAC address is
invalid.
Defective main
PWB.
Replace the main PWB (See page 1-5-27).
0150 Engine PWB (EEPROM) error
Data read from EEPROM is judged
abnormal.
Defective
EEPROM.
Replace the engine PWB (See page 1-5-
28).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
0170
Billing counting error
Defective main
PWB.
Replace the main PWB (See page 1-5-27).
0420 Paper feeder communication error
Communication error between engine
PWB and optional paper feeder.
Improper installa-
tion paper feeder.
Follow installation instruction carefully again.
Defective harness
between PF main
PWB (YC3, YC5)
and paper feeder
interface connec-
tor, or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to the
service manual for the paper feeder).
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Defective harness
between engine
PWB (YC33) and
paper feeder inter-
face connector, or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
0600 Expanded memory (DIMM) installing
error
The expansion memory modules (DIMM)
are not correctly mounted.
Improper installa-
tion expanded
memory (DIMM).
Check the installation of the expanded mem-
ory (DIMM) and remedy if necessary (See
page 1-2-5).
0610 Expanded memory (DIMM) error
The expansion memory modules (DIMM)
mounted on the main PWB does not
operate correctly.
Defective
expanded memory
(DIMM).
Replace the expanded memory (DIMM)
(See page 1-2-5).
Defective main
PWB.
Replace the main PWB (See page 1-5-27).

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
