Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-5
0640 Hard disk error Defective hard
disk.
Replace the hard disk (See page 1-2-7).
Defective main
PWB.
Replace the main PWB (See page 1-5-27).
0930 I2C bus error Defective RFID. Replace the RFID.
Defective drum
PWB (EEPROM).
Replace the drum unit (See page 1-5-14).
Defective engine
PWB (EEPROM).
Replace the engine PWB (EEPROM) (See
page 1-5-28).
Defective main
PWB.
Replace the main PWB (See page 1-5-27).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
1010 Lift motor error
When the lift motor is driven, the lift
motor over-current detection signal is
detected continuously for 50 times (5 s)
at 100 ms intervals.
After the lift motor is driven, the ON sta-
tus of lift limit sensor cannot be detected
for 8 seconds.
The cassette installed confirmation mes-
sage is displayed on the printer opera-
tion panel, and even if the cassette is
opened and closed, the cassette
installed confirmation message is dis-
played 5 times successively.
Defective bottom
plate elevation
mechanism in the
cassette.
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Defective drive
transmission sys-
tem of the lift
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective lift motor. Replace the lift motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
1020
1030
1040
1050
PF lift motor error
(Option paper feeder)
When the PF lift motor is driven, the PF
lift motor over-current detection signal is
detected continuously for 50 times (5 s)
at 100 ms intervals.
After the PF lift motor is driven, the ON
status of PF lift limit sensor cannot be
detected for 8 seconds.
The cassette installed confirmation mes-
sage is displayed on the printer opera-
tion panel, and even if the cassette is
opened and closed, the cassette
installed confirmation message is dis-
played 5 times successively.
1020: Paper feeder 1
1030: Paper feeder 2
1040: Paper feeder 3
1050: Paper feeder 4
Defective harness
between PF lift
motor and PF main
PWB (YC7), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to the
service manual for the paper feeder).
Defective bottom
plate elevation
mechanism in the
cassette.
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.(Refer to the service manual for the
paper feeder).
Defective drive
transmission
system of the PF
lift motor.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.(Refer to the
service manual for the paper feeder).
Defective PF lift
motor.
Replace the PF lift motor. (Refer to the ser-
vice manual for the paper feeder).
Defective PF lift
limit sensor.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Defective PF cas-
sette size switch.
Replace the PF cassette size switch.(Refer
to the service manual for the paper feeder).
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
