Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-13
4201 Laser output error (Black)
The pin photo signal (PDN) is not output
from PD PWB Y for one second while
laser is emitted.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
4202 Laser output error (Cyan)
The pin photo signal (PDN) is not output
from PD PWB M for one second while
laser is emitted.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
4203 Laser output error (Magenta)
The pin photo signal (PDN) is not output
from PD PWB M for one second while
laser is emitted.
Defective harness
between APC
PWB M and engine
PWB (YC607), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective APC
PWB M.
Replace the laser scanner unit (See page 1-
5-42).
Defective PD PWB
M.
Replace the laser scanner unit (See page 1-
5-42).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
4204 Laser output error (Yellow)
The pin photo signal (PDN) is not output
from PD PWB Y for one second while
laser is emitted.
Defective harness
between APC
PWB Y and engine
PWB (YC607), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective APC
PWB Y.
Replace the laser scanner unit (See page 1-
5-42).
Defective PD PWB
Y.
Replace the laser scanner unit (See page 1-
5-42).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
4600 LSU cleaning motor error
When the LSU cleaning motor is driven,
the LSU cleaning motor over-current
detection signal is detected continu-
ously for 50 times (5 s) at 100 ms inter-
vals.
Defective harness
between LSU
cleaning motor and
engine PWB
(YC37), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission sys-
tem of the LSU
cleaning motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective LSU
cleaning motor.
Replace the LSU cleaning motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
