Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-12
2610
2620
2630
2640
PF paper feed motor error
(Option paper feeder)
The PF paper feed motor of paper feeder
1 ready input is not given for 2 seconds
during the PF paper feed motor is ON.
2610: Paper feeder 1
2620: Paper feeder 2
2630: Paper feeder 3
2640: Paper feeder 4
Defective harness
between PF paper
feed motor and PF
main PWB (YC6),
or improper con-
nector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective PF paper
feed motor drive
transmission
system.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any (Refer to
the service manual for the paper feeder).
Defective PF main
motor.
Replace the PF main motor.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Defective printer’s
engine PWB.
Replace the printer’s engine PWB (Refer to
the service manual for the printer).
2830 Developing motor K error
The developing motor K ready input is
not given for 5 seconds during the devel-
oping motor K is ON.
Defective harness
between develop-
ing motor K and
engine PWB
(YC26), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission
system of the
developing motor
K.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Improper installa-
tion intermediate
transfer unit.
Check the installation of the intermediate
transfer unit and reinstall them if necessary
(See page 1-5-16).
Defective develop-
ing motor K.
Replace the developing motor K.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
4000 Polygon motor error
The polygon motor ready input is not
given for 10 seconds during the polygon
motor is ON.
Defective harness
between polygon
motor and engine
PWB (YC604), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective laser
scanner unit.
Replace the laser scanner unit (See page 1-
5-42).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
