Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-24
7404 Developing unit Y non-installing error
The EEPROM of the developing PWB Y
does not communicate normally.
Incompatible developing unit Y is
installed.
Faulty connection
of the connector
between the devel-
oping PWB Y and
drum relay PWB.
Check the installation of the developing unit
Y and drum relay PWB and reinstall them if
necessary (See page 1-5-12).
Defective harness
between drum
relay PWB (YC2)
and engine PWB
(YC619), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Installation of
incompatible
developing unit Y.
Install developing unit Y compatible with the
specifications to the printer.
Defective toner
sensor Y.
Replace the developing unit Y (See page 1-
5-12).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
7411 Drum unit K non-installing error
The EEPROM of drum PWB K does not
communicate normally.
Incompatible drum unit K is installed.
Faulty connection
of the connector
between the drum
PWB K and drum
relay PWB.
Check the installation of the developing unit
K and drum relay PWB and reinstall them if
necessary (See page 1-5-12).
Defective harness
between drum
relay PWB (YC1)
and engine PWB
(YC34), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Installation of
incompatible drum
unit K.
Install drum unit K compatible with the spec-
ifications to the printer.
Defective drum
PWB K.
Replace the drum unit Y (See page 1-5-14).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
