Kyocera ECOSYS P7035cdn - Page 99

2PR
1-5-13
5. Check or replace the developing unit and
refit all the removed parts.
NOTE:
Remove the cap before installing the new
developing unit.
When reinstalling the developing unit, press
it down until the lever of developing unit is
engaged with the notch.
Figure 1-5-15
Lever
Lever
Developing unit
Developing unit
(New)
Cap
