10-26
Troubleshooting > Troubleshooting
Clearing Paper Jams
If a paper jam occurs, the message display will display "Paper Jam." and the machine will stop.
Refer to these procedures to remove the jammed paper.
Jam Location Indicators
1 Shows the location of a paper jam.
2 Displays the Help screen.
If a paper jam occurs, the location of the jam will be displayed on the message display as well as the clearing instructions.
After you remove the jam, the machine will warm up again and the error message will be cleared. The machine
resumes with the page that was printing when the jam occurred.
For details on Help Screen, refer to the following:
Help Screen (page 2-12)
Paper Jam Location
Indicator
Paper Jam Location
Reference
Page
A Multi Purpose Tray page 10-27
B Cassettes 1 to 5 page 10-28
C Duplex Unit page 10-29
D Inside the Machine page 10-30
E Top Tray / Inside Rear Cover page 10-31
F Large Capacity Feeder page 10-33
G Duplex unit (when Large Capacity Feeder is
installed)
page 10-34
